多功能混凝土運輸攪拌車罐子不轉的原因
使用多功能混凝土運輸攪拌車,不可避免的會出現罐子不轉的現象,那么這是什么原因呢?我們需要檢查哪些部分?下面中科聚峰公司小編為您詳細介紹一下。
The use of multi-functional concrete transport mixer will inevitably lead to the phenomenon that the tank doesn't rotate, so what's the reason? What parts do we need to check? The following is a detailed introduction of Zhongke Jufeng company.
1. 引擎故障(不是不可能,隆隆的聲音);
1. Engine failure (not impossible, rumbling sound);2. 檢查液壓油是否泄漏(用破管更換油管,用破密封更換油封);3、檢查多功能攪拌混凝土運輸汽車散熱器風扇反過來,懷特液壓油乳化:不,液壓油溫度超過90度,液壓系統,沒有壓力,罐不轉(這種情況不要著急,冷卻水液壓泵,液壓馬達,液壓油溫度、jar可以旋轉。取出材料,固定散熱器或更換液壓油);4. 傳動軸損壞損壞10個字節(a損壞應立即更換傳動軸;B傳動軸ok);5. 在運輸過程中,我沒有注意。jar停了!混凝土掉進去了,罐子翻不了。
2. Check whether the hydraulic oil leaks (replace the oil pipe with a broken pipe and replace the oil seal with a broken seal); 3. Check the radiator fan of the multi-functional mixing concrete transport vehicle, in turn, white hydraulic oil emulsification: No, the hydraulic oil temperature exceeds 90 degrees, the hydraulic system, there is no pressure, and the tank does not rotate (in this case, do not worry, the cooling water hydraulic pump, hydraulic motor, hydraulic oil temperature, jar can rotate). Take out the material, fix the radiator or replace the hydraulic oil); 4. The transmission shaft is damaged and damaged by 10 bytes (if a is damaged, replace the transmission shaft immediately; B is OK); 5. I didn't pay attention to it during the transportation. Jar stopped! The concrete fell in and the jar couldn't be turned over.
6. 液壓泵損壞(情況比較復雜,腹瀉嚴重,其他損壞);以上6種情況出現,而混凝土不凝,液壓馬達、減速機無故障,可采用應急裝置,用另一臺多功能混凝土運輸攪拌機的液壓泵驅動液壓馬達轉動即可,混凝土放出來,再檢修!
6. The hydraulic pump is damaged (the situation is complex, diarrhea is serious, and other damages); the above six situations occur, but the concrete is not coagulated, and the hydraulic motor and reducer are free of faults. The emergency device can be used. The hydraulic pump of another multi-functional concrete transportation mixer can drive the hydraulic motor to rotate, and the concrete can be put out for maintenance!
以上是中科聚峰混凝土運輸攪拌車廠家為大家介紹的相關內容,想要了解更多內容,歡迎訪問網站:http://pheenet.cnThe above is the relevant content introduced by the manufacturer of Zhongke Jufeng concrete transport mixer for you. To learn more, please visit the website: http://pheenet.cn
